Vortex flow sensor 236
The flow sensors of Type 236 are based on the principle of the Kármán vortex street.
They differ from their counterpart, the Type 210, through their brass housing. The vortex flow sensors of Type 236 offer a wide range of configuration options for electrical power supply and output interfaces. Due to their maintenance-free design without moving parts, the sensors are resistant to contamination. Furthermore, they are characterized by a low pressure drop and exceptionally high measurement accuracy.
Optional variants with an integrated temperature sensor are available.
- Temperature-insensitive measuring principle
- Excellent media resistance (measuring element without media contact)
- Optionally with temperature measurement
- Low pressure loss with high measurement accuracy
- Dirt-insensitive measuring element
- Temperature measurement directly in the medium
- Drinking water approvals KTW, W270, ACS, WRAS
- High measurement accuracy
Vortex flow sensor 236
Product feature
Flow measurement principle
Vortex flow rate
Measuring range flow rate Overview
0,9 ... 240 l/min
Nominal width
8; 10; 15; 20; 25; 32
Accuracy < 50 % measuring range end value Water
<1 %FS
Accuracy > 50 % measuring range end value Water
<2 % (Measured value)
Switch-on delay
<100 ms (Immediate response time; can be used for tapping operation)
Response time
5 ... 500 ms
Repeatability
±0,5%
Sensor type
Flow sensor, optionally with temperature measurement
Measuring range flow rate
0,9 ... 240 l/min
Temperature measuring range
-40 ... 125 °C
Temperature measuring principle
PT1000 (Class B DIN EN 60751)
Field of application
Media
Heating water with standard additives; Drinking water; Other media on request
Medium temperature
-15 ... 125 °C (Non-freezing media)
Maximum test pressure at 40 °C media temperature
18 bar
Cavitation
>5,5 (Equation for avoiding cavitation: P abs outlet / P difference)
Maximum system pressure media temperature up to 90 °C
7 bar
Maximum pressure impact resistance at 90 °C media temperature
on request
Recommended minimum system pressure
1 bar
Ambient condition
Ambient temperature
-15 ... 85 °C
Storage temperature
-30 ... 85 °C
Material
Sensor paddle with media contact
ETFE
Housing with media contact
Brass (CuZn21Si3P); PA6T/6I (40 % glass fibre)
Sealing material with media contact
FKM; EPDM (perox.)
Electrical data
Electrical connection
M12x1 connector
IP protection class
IP 65
Temperature output
PT1000
Inverse-polarity protection
Short-circuit and reverse polarity protected. Each connection against each other with max. supply voltage.
Approval
EMC compatibility
CE-compliant in accordance with EN 61326-2-3
Drinking water
Plastic parts with KTW and W270 approval; WRAS; ACS
Temperature measurement
Influence Self-heating temperature sensor
1 K/mW
Influence Conduction resistance to connector
0,8 Ohm
Vortex flow sensor 236
Vortex flow sensor 236
Download the product-specific technical documents here in the language of your choice or open it in a new window . You can find all product and business-relevant documents on our central download page
.
EN-GB
Data Sheet 236
Data Sheet
PDF
DE
EN-GB
FR
Operating Instruction 236
Operating Instruction
PDF
EN-GB
Drinking water authorisation WRAS
Certificate
PDF
FR
Certificate 235 236
Certificate
PDF
Vortex flow sensor 236
Order number
Accessories
114563
Angled cable socket
for M12x1 connector; With cable; (with temperature output); 200 cm; 5-pole
114564
Straight cable socket
for M12x1 connector with cable; (with temperature output); 200 cm; 5-pole
114604
Angled cable socket
for M12x1 connector; With cable; 200 cm; 3-pole
114605
Straight cable socket
for M12x1 connector with cable; 200 cm; 3-pole
115024
Straight cable socket
for M12x1 connector with screw terminals; 5-pole
